13
You may use a Y-Adaptor (not included) for an additional water feed for another
appliance, for example a washing machine. This is only applicable for cold water
mains. A Y-Adaptor is available from most DIY stores.
About the Safety Supply Hose
The safety supply hose consists of the double walls. The hose’s system guarantees
its intervention by blocking the ow of water in case of the supply hose breaking
and when the air space between the supply hose itself and the outer corrugated
hose is full of water.
Water mains
Y-Adaptor
(not included)
Connect
to another
appliance
if required.
Water supply hose
17. Attach the toe panel mounting brackets to
the toe panel. Align the screw holes, then
use the 4 screws ST4x14 to secure the toe
panel.
18. Insert the toe panel to the dishwasher.
19. Make sure your plumbing is suitable for use
with the dishwasher. If in doubt contact
a qualied plumber. This unit MUST BE
connected to COLD WATER MAINS using the
new water inlet hose. OLD HOSE SETS MUST
NOT BE RE-USED. The water pressure from
the water mains needs to be at a minimum
of 0.04 MPa and a maximum of 1.00MPa.
• Connect one end of the safety water
supply hose to your dishwasher, and
then connect the other end of the hose
to your water mains. Please ensure the
black rubber seal is in place.
• After connecting the hose, turn on your
water mains and check for leaks.
• Connect the dishwasher to the mains
socket.
