Controls and Display
Output Control
The output control thumbwheel establishes the maximum amount of power
available to the trailer brakes when braking. The only exception would be when
the manual control is setup for 100% braking, see "Set manual control out-
put and brake light switches".
As the output control is rotated, a ashing display shows the setting. When
turned to the right, more power will be available to the brakes when turned to
the left, less power will be available.
Display ashes the setting for a few seconds after adjustment is complete.
The output control would be adjusted during initial setup, when trailer load
changes, when different trailers are used or when adjustment is needed for
changing road or driving conditions.
The output setting is shown on the display when a trailer is connected and the
brake pedal is pressed or the manual control is actuated. The output setting is
shown as through
Sensitivity Control
The sensitivity control adjusts trailer brake aggressiveness. The trailer brakes
become more aggressive as the switch is moved toward the driver.
To view the sensitivity setting on the display, move the control slightly. The set-
ting will ash.
Sensitivity adjustment has no effect on the manual control. The sensitivity
control would be adjusted for individual driver preference, trailer load changes
or changing road conditions.
