2.3 Environmental
Temperature
Operating: –40°C to +85°C
Storage: –50°C to +90°C
Humidity
95% RH (non-condensing) at 38°C
Shock and Vibration
Shock: per SAE J 1378 paragraph 5.6
12 shocks in each direction along each axis (72
shocks total). 44 to 55g amplitude, half sine of
9 to 13 ms.
Vibration: per SAE J 1378 paragraph 5.5
2 hours along each axis. Double amplitude of
1.52mm from 10-80-10 Hz (10g max) at intervals
of 1 minute.
2.2 Mechanical
Display
Battery state-of-charge: 10-bar, tri-color LED.
Hardware Kit
Mounting bracket, thumbnuts or M4 Hex nuts (2), lock
washers (2).
Panel Cutout
52mm, 2 ¹/16” diameter
Mating Connector
Molex
Housing: 39-01-2085
Pins: 39-00-0039 (18-24 AWG)
39-00-0078 (16 AWG)
