ROUGH-IN DRAWINGS RD13
TBP - Tea Brewer
9.13 in
[23.2 cm]
9.14 in
[23.2 cm]
29.38 in
[74.6 cm]
4.00 in
[10.2 cm]
16.63 in
[42.2 cm]
25.70 in
[65.3 cm]
6.27 in
[15.9 cm]
9.94 in
[25.3 cm]
9.59 in
[24.3 cm]
5.00 in
[12.7 cm]
13.46 in
[34.2 cm]
22.91 in
[58.2 cm]
10.97 in*
[27.9 cm]
* Width with TCO38 dispenser in place.
