ROUGH-IN DRAWINGS RD12
TB - Tea Brewer
16.61 in
[42.2 cm]
10.11 in
[25.7 cm]
34.20 in
[86.9 cm]
11.71 in
[29.7 cm]
22.67 in
[57.6 cm]
22.29 in
[56.6 cm]
3.41 in
[34.1 cm]
22.82 in
[58.0 cm]
1.20 in
[3.0 cm]
