ILLUSTRATED PARTS/RECOMMENDED PARTS IP15
CB/CBP/CBS, ILLUSTRATED PARTS/RECOMMENDED PARTS 032720H
ITEM # PART # DESCRIPTION
1 WC-58117
COVER, TOP ALPGT/D500GT/D60GT TLP/TCTS/
CBS/GEMSS
2A
a,b,c,d,f
WC-3503 LEG, 3/8”-16 STUD SCREW BUMPER
2B
e
WC-3528
LEG, 4” ADJUSTABLE 3/8-16 THRD ITALIAN
STYLE
3A
a,c,d,e
WC-13043-106 HARNESS, ASSY TCTS/PTT3/CBS/RSTB/STB
3B
b,f
WC-13044 HARNESS, ASSY TCTS/PTT3-30
4 WC-43134
O’RING, .426 X 9/16 O.D X .070 WALL EDPM
TCTS
5
a,b,c,d,f
WC-3518 LEG, GLIDE 3/8”-16 STUD SCREW
6 WC-66079 SPOUT ASSY , DILUTION PLASTIC
7A
a,c,e
WC-786-104
CONTROL MODULE, UCM 120V TEA/ COMBO/
SWEET TEA BREWER
7B
b,d,f
WC-729-104
CONTROL MODULE, UCM 220V TEA/ COMBO/
SWEET TEA BREWER
8A
a,c,d,e
WC-3398
BREW CONE, ASSY STD TEA NON METAL W/
BLU SPLASH POCKET
8B
b,f
WC-37256
KIT, BREW CONE GOURMET NON-METAL FOR
TEA UNITS
9 WC-8531 RAIL, BASE TCTD
10A
a,c,e
WC-895-105 VALVE, INLET DUAL 120V 10W 2 GPM X .5 GPM
10B
b,d,f
WC-878-102
VALVE, INLET DUAL 240V 6W 1.0 GPM TANK X
.5 GPM DILUTION
11 WC-8556*
HEATSINK, ASSY DV ALPDS/D500AP TCTD/
PTTD
12A
a,e
WC-102*
SWITCH, TOGGLE NON-LIT SPST 15A 125/6A
250VAC RESISTIVE
12B
b,c,d,f
WC-103
SWITCH, TOGGLE NON-LIT DPST 25A
125/250VAC RESISTIVE
13 WC-5310* TUBE, 5/16 ID x 1/8W SILICONE GEN USE
14 WC-5231* COMPOUND, HEAT SINK 5OZ
15A
a,c,e
WC-889*
VALVE, DUMP LEFT 120V 12W ALPHA’S/D1000/
GEM-12/TLP
15B
b,d,f
WC-860 VALVE, DUMP LEFT 220V 12W
16A WC-2977K
1*
KIT, SPRAYHEAD FITTING METAL
16B WC-2977-101K
2
KIT, SPRAYHEAD FITTING PLASTIC
17 WC-29044-101 SLEEVE, OVERFLOW
18 WC-29025* SPRAYHEAD, PURPLE ADVANCE FLOW
19 WC-37255* KIT, DUAL VALVE WATER INLET
20A
a,c,e
WC-1200 CORD, 14/3 SJTO 6’ BLK W/PLUG
20B
b,d
WC-1231-102
CORD, 2.5 mm² 90ºC 36A 450/750 V STRIPPED
W/FERRULES ONE END
20C WC-1256 CORD, 1.5mm² X 3 W/GB-2099 & C19 CHINA
21A
a,e
WC-1408 CORD GRIP, 7/8” O.D.
21B
b,d
WC-1419 CORD GRIP, 1/2” ROMEX
21C
c
WC-1412 CORD GRIP, 3/4” FOR METAL CORD TO .81”OD
ITEM # PART # DESCRIPTION
22 WC-390162 LABEL, UCM OVERLAY CBP/CB CURTIS LOGO
23 WC-37252
KIT, HOT WATER FAUCET REPLACEMENT
ALPGT/D60GT/D500GT
24
e
WC-85008
SUPPORT, DECK EXTENDED SS PTTD /SCPTTD
SCPTTDP
25
b,f
WC-596K KIT, NOISE FILTER EMI 250V/30A 1PH
26
a,b,c,d,f
WC-61709 SHELF, SS CBS
27 WC-3417-P
BREW CONE,ASSY W/SPLASH POCKET BRWN
STYLIZED GEMIN HOT COFFEE
28A WC-4320
1
O’RING, 0.487I.D.x 0.693OD x0.103CS BUNA-N
#112
28B WC-43089
2
GASKET, 1.00OD X .625 I.D. X .030 THK WHITE
EPDM 70 SHORE
29A WC-4213-P
1
NUT, 5/8 LOCK PLATED
29B WC-4212-02
2
NUT, 5/8-18 JAM PLASTIC
30 WC-847
VALVE, INLET 2 GPM 120V 10W GEN USE
BROWN BODY
31 WC-2401-P ELBOW, 3/8 NPT X 1/4 FLRE PLTD PLATED
32 WC-2705 TEE, 1/4 X 1/4 FLARE X 3/8 NPT PLATED
33A
a,c
WC-53169-12
TUBE ASSY, BRAIDED 1/4 FLARE X 11-1/4” LG
W/FITTINGS
33B
e
WC-53169-7
TUBE ASSY, BRAIDED 1/4 FLARE X 6-3/4” LG W/
FITTINGS
34 WC-390241 LABEL, FLAVOR OPTIONS & BREW BUTTONS
35 WC-12020 VALVE, INLET .5 GPM 120V 9W CB
36 WC-4616
SCREW, 1/4-20 x 1/2 PHILLIPS PAN HEAD
STAINLESS STEEL
37
b,f
WC-314 POWER BLOCK, 5 STATION
38A WC-37132
KIT, VALVE REPAIR FOR INVENSYS WC-
820WDR,WC-821WDR, WC-844WDR
(OLDER UNITS)
38B WC-37132-101
KIT, VALVE REPAIR FOR DELTROL WC-
820WDR,WC-821WDR, WC-844WDR
(NEWER UNITS)
39 WC-4607 SCREW, 5/16-18x3/8”SS PAN HEAD
40 WC-4426 SCREW, 8-32x3/8 PH HEAD TRUSS
41 WC-4458
SCREW, 6-19 x 1/2” PHIL PAN HD TRI-LOBULAR
60-1 THRD FORMING
42 WC-4525 SCREW, 8-32x1/4PHILLIPS TRUSS HD SS
43 WC-4439 SCREW, 6-32x¼ PHIL PAN HD SS
44 WC-1806 SEAT CUP, SILICONE USE ON WC-1809 FAUCET
45
f
WC-1522 SOCKET, POWER INLET 16A/250V SNAP-IN
CB, CBP, CBS Series - Main Chassis - Parts List
a
CB, CB2
b
CB3 (older units)
c
CB6
d
CBS30098
e
CBP
f
CB3 (newer units)
1
Units built 05/15/17 and later.
2
8QLWVEXLOWEHIRUH7KHSODVWLFÀWWLQJDVVHPEO\PD\EHUHSODFHGZLWKDVWDLQOHVVVWHHOÀWWLQJNLWLWHP$
%UHZVHWWLQJVPXVWEHFKDQJHGZKHQFKDQJLQJÀWWLQJW\SHV6HHLQVWUXFWLRQVWKDWFRPHZLWKQHZÀWWLQJ
5HFRPPHQGHGSDUWVWRVWRFN
