Curtis G3 User Manual

56
User manual Curtis G3 Tea/Coffee Combo brewer
Appendix: Technical data
Technical data for coffee machine
External dimensions Width 256mm
Height 869mm
Depth 578mm
Water tank volume 6.1 litres
Brewed fi ll weight approx. 25.9kg
Water connector 3/8“
Water pressure Min: 0.14MPa, Max: 0.62MPa
Min. fl ow rate 3.8 l/min.
Use at elevation above sea level < 2.000m
Nominal power rating 2787W
Power supply 230VAC
50 / 60Hz (1 PH)
On-site fuse 12.1A
Protection class IP X0
Calibration pressure Boiler 0.32MPa (3.2bar)
Continuous sound pressure level
(Lpa)
< 70dB(A)
Ambient temperature +5°C to maximum +35°C
(empty the water system in case of frost).
Maximum humidity 80 % relative humidity without condensation.
Do not use device outdoors.
Installation surface/water spray The device must be placed and leveled on
ahorizontal, sturdy, water-resistant, and
heatproof base.
The device must not be cleaned using awater
jet. The device must be installed where it is
protected against water spray. The device must
not be located on asurface that is sprayed or
cleaned with awater hose, steam jets, steam
cleaner, or similar devices.
Appendix: Technical data

Curtis G3 Specifications

General

Brand	Curtis
Model	G3
Category	Brewing Systems
Language	English
