Description
BREWCONE,UNIVERSAL7.38"D.
TIMER,BREWSELECTOR120V2-20MINGEM-120A/RU'S(NEWERUNITS)
TIMER,BREWSELECTOR120VGEM-120A(OLDERUNITS)
CONTROLBOARD,LIQUIDLEVEL
SPRAYHEAD,RED(.131DIA)
KIT,PROBE,ASSYWATERLEVELW/HEXFITTING,O-RING&NUT
LABEL,SWITCHPANELGEM120ACURTIS(NEWERUNITS)
LABEL,SWPANELGEM-120ACURTIS(OLDERUNITS)
KIT,ELEMENT,HEATING1.6KW120VW/JAMNUT&SILICONEWASHERS
KIT,ELEMENT,HEATING2KW220VW/JAMNUT&SILICONEWASHERS
POWERCORD,6'14/3BLKSJTO
VALVE,INLET1GPM120V10WALP/AP/TLPYELLOWBODY
THERMOSTAT,CAPILLARYSPST277V22AGENUSE
KIT,VALVEREPAIRFORWC-866,WC-889,WC-816,WC-817,WC-818
VALVE,DELTROLDUMPRIGHT120V.
FAUCET,HOTWATERW/JAMNUT
LIGHT,BREW115VGREEN
LIGHT,BREW220V
SWITCH,ROCKER120VRED
SWITCH,ROCKERBREW120VGREEN
FITTING,SPRAYHEADULTEM
TUBE,5/16"I.D.SILICONEGENUSE
THERMOSTAT,MANUALRESET120/240VAC25A220DEGFMAX
THERMOSTAT,HILIMITHEATERCONTROLDPST277V40A
ELEMENT,WARMERASSY100W120VWITHSILICONEBOOTS
SWITCH,TOGGLESPST25A125/250VACRESISTIVE
LEG,SCREWBUMPER3/8-16STD
KIT,BREWCONEW/BASKETSS71/8"DELUXEBLKHANDLE(OPTIONAL)
COVER,FRONTGEM-120A/120P/230A/200R/300IL/600ILD
COVER,TOPALPGT/D500GT/D60GTTLP/TCTS/CBS/GEMSS
PLUG,DRAINPPRED
KIT,VALVEREPAIR(USEONWC-825WC-826)
WASHER,.35GPM.5"USEONWC-825
LIDASSEMBLY,TANK
TANK,COMPLETEGEM-120A120V
TANK,COMPLETEGEM-120A120/220VDV
LABEL,BOTTOMGEM-120A
1
2
2A
3
4
5
6
6A
7
7A
8
9
10
11
12
13
14
14A
15
16
17
18
19
19A
20
21
22
23
24
25
26
27
28
29
30
30A
31
WC-3621-101
WC-603-101
WC-603RDS
WC-608-101
WC-2936
WC-5502-01
WC-3920-01
WC-3920T
WC-904-04
WC-906-04
WC-1200
WC-826L
WC-517
WC-3763
WC-817
WC-1809
WC-207
WC-203
WC-114R
WC-122
WC-2977-101
WC-5310
WC-523
WC-522
WC-970
WC-102
WC-3503
WC-3338
WC-5452
WC-58117
WC-43058
WC-3765
WC-829
WC-37008
WC-5466
WC-54133
WC-3920B
Item
Nº
Part
Nº
PAPER FILTERS
Part Number
Description
CR-12
CR-10
FILTERFORBREWCONEWC-3338(500/PKG)
FILTERFORBREWCONEWC-3621-101(1000/PKG)
