4 CONTROLS
8
Z
Y
AB
AA
V
W
X
NN
P
E
1
4
F
0
050
HOURS
x 100
545
10
10
!
16
12 14
140
88
60
104
138
280
190 220
40
15 35
20 30
25
0000
0
3
4
1
2
F
C
COOLANT
A
B
C
D
E
F
F
G
H
J
K
L
Side Panel Rotated 90 Degrees
For Clarity
Manual
Transmission
Automatic
Transmission
R
S
T
U
STOP
M
P
R
N
D
2
L
A Tachometer
B Hour Meter
C Fuel Gauge
D Voltmeter
E Temperature Gauge
F Turn Signal Indicator
G Oil Pressure Light
H Glow Plug Light
J Service Brake Fluid Light
K Parking Brake Light
L High Beam Indicator
M Ignition Switch
N Gear Selector
P Accessory Power Plug
R Hand Throttle
S Governor Control
T Light Switch
U Horn Button
V Clutch Pedal
W Service Brake Pedal
X Accelerator Pedal
Y Differential Shift Cable
Z Parking Brake Lever
AA Remote Hydraulics Control
AB Hydraulic Lift Control
