OPERATION
19
STARTING AND DRIVING
To reduce the possibility of roll-back which could result in severe injury or vehicle damage, do not release the
service brake until motor has started.
All vehicles are equipped with an interlock system that disables the controller and prevents the vehicle from being
operated or moved while the charger is connected. Disconnect the AC charger cord from the vehicle charger pigtail
and properly store the cord prior to moving the vehicle.
To operate the vehicle:
• Operator is to be properly seated facing forward with feet on the floor.
• Apply pressure to the brake pedal, place the key in the key switch and turn it to the F or R position.
• Slowly press the accelerator pedal to actuate the electric motor.
• When the accelerator pedal is released, the motor controls the deceleration. To stop the vehicle more quickly, press
the brake pedal
.
• When the motor of operation is stopped, the parking brake is automatically set.
NOTICE: When the direction selector is in the reverse position, a warning signal will sound to indicate that
the vehicle is ready to run in reverse.
STARTING VEHICLE ON A HILL
Do not hold vehicle on hill by using accelerator and motor. Leaving motor in a stalled condition for more than
3 - 4 seconds will cause permanent damage to motor.
To reduce the possibility of permanent damage to the drive system, it is important to prevent excessive roll-back when
starting the vehicle on a hill.
A stalled motor condition may lead to a fault detection and power being interrupted. To resume operation cycle the key
to N (Neutral) and back to the desired direction.
Coasting
To reduce the possibility of severe injury or death from coasting at above recommended speeds, limit speed
with service brake.
On steep hills or ramps it is possible for vehicles to coast at faster than normal speeds encountered on a flat surface.
To prevent loss of vehicle control, speeds should be limited. Limit speed by releasing the accelerator pedal and apply-
ing pressure to the brake pedal. Severe damage to the drive train components due to excessive speed may result
from driving the vehicle above specified top speed. Damage caused by excessive speed may cause a loss of control,
is costly, is considered abuse, and will not be covered under warranty.
PARKING THE VEHICLE
This vehicle is equipped with the IntelliBrake
TM
, an automatic parking brake.
To park the vehicle:
1. Press the brake pedal to stop the vehicle.
2. Turn the key switch to/direction selector OFF.
3. Remove the key from the ignition to prevent unauthorized use.
LABELS AND PICTOGRAMS
Vehicles may be labeled with pictograms as a method of conveying information or warnings. The SAFETY Section of
this manual explains the labels that are used on this vehicle. Maintain vehicle labels and decals in legible condition.
Replacement labels and decals are available from an authorized dealer or through service parts.
