GENERAL SPECIFICATIONS
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
9
Owner’s Guide
GENERAL SPECIFICATIONS
MODEL: REFRESHER
®
FS4
TYPE: GASOLINE POWERED REFRESHMENT VEHICLE
Engine:
13 hp (9.7 kW) Exceeds SAE J1940 Standard, 4 cycle, 24.5 ci (401 cc) single cylinder, air-cooled by Kawasaki
z
Valve Train:
Overhead valve z Fuel System: Fixed float bowl with remote pulse fuel pump
z
Lubrication
Pressurized oil system, spin-on oil filter z Ignition: Electronic spark/magneto
z
Balancer: Internal counter rotating balance shaft z
Air Cleaner:
Replaceable dry cartridge
Electrical: Starter/Generator, solid-state regulator, 12 Volt maintenance free battery (425 CCA, 60 minute reserve)
Drive Train:
Automatic, continuously variable transmission (CVT)
Brakes:
Dual rear wheel mechanical self-adjusting drum brakes.Single point park brake release with self-compensating system
Transaxle: Differential with helical gears, ground speed governor, forward/reverse
Canopy: Sunbrella®
Beverage Unit: 5000 Series Aluminum, Super Durable TGIC Polyester Powder Coating
Beverage Unit Storage Capacity:
z Cold Storage Cabinets: 4 z Trash Bin Volume 3.4 cu ft (0.96 m3)
z
Merchandising Capacity
21.1 cu ft (.59 m3) z Work Space:
13 ft2 (4 m2)
Dimensions Performance
Overall Length 147 in (366 cm) Seating Capacity 1 Person Std, 2 Persons Optional
Overall Width 54 in (137 cm) Dry Weight 1470lb (661 kg)
Overall Height (No Canopy) 49 in (124 cm) (Top of steering wheel)
ur
e
g
1508 lb (684 kg)
Overall Height (With Canopy) 80 in (203 cm) Vehicle load capacity 1015 lb (460 kg)
Wheel Base
93.5 in (235 cm) Outside Clearance Circle
Left 26.8 ft (8.1 m), Right 25.2 ft (7.6 m)
Front Wheel Track 39.6 in (100 cm) Intersecting Aisle Clearance N/A
Rear Wheel Track 39.5 in (100 cm)
Gnd Clearance @ Differential 4.5 in (11 cm)
Vehicle Power Towing Capacity N/A
Power Source 4 Cycle 24.5 cu in (401 cc)
Steering & Suspension
Valve Train Single Cylinder OHV
Steering Self-compensating rack and pinion
Horsepower (kW) 13 hp (10.1 kW) Exceeds SAE J1940 Std.
Front Suspension Leaf springs with hydraulic shock absorbers
Electrical System
Starter/Generator. Solid State Regulator
Rear Suspension
Heavy Duty leaf springs with hydraulic shocks
Batteries (Qty, Type) One, 12 Volt Maintenance Free
Service Brake 4 Wheel hydraulic, front disc/rear drum
Key or Pedal Start Pedal
Parking Brake Mechanical hand brake
Air Cleaner Industrial Rated Dry Filter
Front Tires Load Star 205/65-10
Lubrication Pressurized Oil System
Rear Tires Load Star 205/65-10
Oil Filte
Spin-On
Body & Chassis
Cooling System Air Cooled
Frame Welded steel with DuraShield™ powder coat
Fuel Capacity
Fuel Capacity
6.2 Gallon (23.5 L) early production tank
5.2 Gallon (19.8 L) early production tank
Front Body & Finish
Injection molded TPO
Drive Train Continuously variable transmission (CVT)
Rear Body & Finish Steel. Base coat/clear coat
Transaxle Differential with helical gears
Standard Color Forest Green
Gear Selection Forward-Reverse
Noise & Vibration
Rear Axle Ratio 17.2:1 (Forward) 17.1:1 (Reverse)
Noise Sound pressure; continued A-weighted equal to or
less than 76 db(A).
Vibration, WBV Highest RMS value of weighted acceleration is
Vibration, HAV less than 2.5 m/s2.
Highest RMS value of weighted acceleration is
less than 2.5 m/s2.
The uncertainty of measurement is 1.08 m/s2
Measurement methods were applied per the ISO 2631 and ISO 5349 standards
Some items shown may be optional equipment
under conditions of typical vehicle surfaces.
PRODUCT SPECIFICATION
PRODUCT OVERVIEW
Speed (Level Ground)
Fwd - 12 mph +/- 0.5 mph (19 kph +/-0.8 kph)
Rev - 11 mph +/- 0.5 mph (17 kph +/-0.8 kph)
Refresher Unit Overview: Refresher unit designed for inventory of unopened, pre-packaged, non-perishable foods for distribution through daily use. This
Refresher unit is not meant for long term food storage or storage of opened food and beverage items. Adherence to local food handling regulations.
Each Refresher Unit Consist Of: Windshield with Frame; Struts and Slate Canopy; 4 Insulated Sliding Drawers with Locks; Slide out Trash/recycle storage bin
system, 2 plastic removable bins; Lower Rear Corner Storage Sections - both sides of endcap; Locking System for Holding & Changing Modules; Polar White
Counter top; Left & Right Side Mirrors.
Accessories: Drawer Dividers
(2); Consumable Ice Bin (1); Candy & Sandwich Tray (1).
Modules: 6" Snack module with one dual-sided pullout polycarbon pegboard, hooks (6), baskets (2) and chip strips (2); 18" Display Module with 4 adjustable
shelves; 18" Cup & Display Module with 2 adjustable shelves/1 cup tray with 4 slots/1 beverage box.
Upper Rear Endcap: Reversible insert for airpots and bottles; 3.0 liter airpots (2); shelves for napkins and bottles on back panel (3); shelves on inside of doors
(6); Coffee/Creamer serving caddy (2).
