Page N-3
689428 Service Parts Manual
THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
REAR AXLE
32 645053 Counter Shaft............................................................................................ 1
33 640744 Ball Bearing (6006) ...................................................................... 1
34 644530 Gear, 38 .................................................................................................... 1
35 639869 Knock Pipe ................................................................................................ 2
36 645059 Ball Bearing (6304) ................................................................................... 2
37 639768 Flanged Hex Head Bolt, M8 - 1.25 x 40mm Lg......................................... 1
38 644536 Gear, 15 .................................................................................................... 1
39 28689G01 Collar, 24 x 7.5mm .................................................................................... 1
40 644541 Gear, 48 .................................................................................................... 1
41 670697 Center Shaft.............................................................................................. 1
42 639774 Clutch Pin.................................................................................................. 1
43 670696 Gear, 61 .................................................................................................... 1
44 639797 Spacer, 20 x 2mm ..................................................................................... 2
45 639872 Differential Case (Includes Items 33, 46, 48 and 49).......................... 1
46 639800 Differential Pair Gear.................................................................... 1
47 26808G01 Hex Head Bolt, M10 - 1.25 x 26mm Lg .............................................. 6
48 28723G01 Differential Shaft........................................................................... 1
49 28697G01 Spring Pin, 4 x 40l........................................................................ 1
50 645061 Ball Bearing (6007) ...................................................................... 1
51 644542 Gear, 62 Complete (Includes Item 50)................................................ 1
52 607938 Castled Nut, M22 - 1.5 ............................................................................. 2
53 639876 Axle Shaft L Complete (Includes Item 55)................................................. 1
54 639881 Axle Shaft R Complete (Includes Item 55) ................................................ 1
55 639836 Ball Bearing (6205DD)........................................................................ 2
56 607939 Axle Case L Complete .............................................................................. 1
57 607940 Axle Case R Complete.............................................................................. 1
58 26814G01 Snap Ring, 52mm ..................................................................................... 2
59 639839 Flanged Hex Head Bolt, M8 - 1.25 x 60mm Lg ......................................... 9
60 639840 Flanged Hex Head Bolt, M10 - 1.25 x 25mm Lg ....................................... 10
61 645063 Shift Shaft Complete ................................................................................. 1
62 639847 Differential Assembly (Includes Items 45, 47 and 51)............................... 1
