I.B. 29C892B
Page 23
Effective 8/99
SECTION 4: TROUBLESHOOTING AND
MAINTENANCE
4-1 LEVEL OF REPAIR
This manual is written based on the assumption that
only unit-level troubleshooting will be performed. If the
cause of a malfunction is traced to an OPTIMizer Hand
Held Programmer, the device should be replaced. The
malfunctioning programmer should be returned to
Cutler-Hammer.
4-2 TROUBLESHOOTING
Refer to Table 4.1 for troubleshooting guidelines.
4-3 MAINTENANCE AND CARE
The OPTIMizer Hand Held Programmer is designed to
be a self contained and maintenance free device,
except for battery replacement. Refer to paragraph 2-
2.1 for battery information.
The OPTIMizer Hand Held Programmer should be
stored in an environment that does not exceed the stor-
age temperature range of -30°C to +85°C. The environ-
ment should also be free of excess humidity. Store the
device in its original packing material or the provided
carrying case.
4-4 RETURN PROCEDURE
The Troubleshooting Guide (Table 4.1) is intended for
service personnel to identify whether a problem being
observed is external or internal to the device. If a prob-
lem is determined to be internal, the device should be
returned to the factory for replacement. To have an
OPTIMizer returned, contact your local Cutler-Hammer
authorized distributor.
4-5 TECHNICAL ASSISTANCE
For information, technical assistance or referral to a
local authorized distributor, contact the Advanced
Product Support Center at 412-494-3750.
