CUTTERMASTER Professional JXT User’s Manual
Page 6
1.3 Journeyman JXT Diagram
1. z-Axis Motor Lift Hand Wheel
2. Motor Lift Lever
3. Stylus
4. Indexing Collar
5. Front Collar
6. y-Axis Table Hand Wheel
7. x-Axis Table Hand Wheel
8. Air Spindle Pivot Base
9. Draw Tube
10. Quill, Spindle
2 - (behind)
9
8
7
6
5
4
3
1
10
