CVS Controls DBQ Series - Page 13

CVS Series DBAQ – Product Bulletin: Dimensions
Nominal
Body
Size Inch
A
D
Class 900/1500
Class 900/1500
Class 2500
Std Bonnet
Ext. Bonnet
RF,
Flanged,
or Weld
Ends
RTJ
Flanged
Ends
RF, Flanged,
or Weld Ends
RTJ Flange
Ends
1/2"
(12.7mm)
Stem
3/4"
(19.1mm)
Stem
1/2"
(12.7mm)
Stem
3/4"
(19.1mm)
Stem
Inches
1
5.56
5.56
6.06
6.06
8.31
9.38
15.38
16.00
2
7.00
7.06
7.69
7.75
9.75
10.50
16.81
17.44
mm
1
141
141
154
154
211
238
391
406
2
179
179
195
197
248
267
427
443
Nominal
Body
Size
Inch
D
Class 2500
Standard Bonnet
Extension Bonnet
1/2"
(12.7mm)
Stem
3/4"
(19.1mm)
Stem
1/2"
(12.7mm)
Stem
3/4"
(19.1mm)
Stem
Inches
1
6.94
8.00
14.00
14.62
2
8.25
9.00
15.31
15.94
mm
1
176
203
356
371
2
210
229
389
405
CVS Series DBAQ – Plain Bonnet
CVS Series DBAQ – Extension Bonnet
