CVS Controls DBQ Series - Page 12

CVS Series DBQ Dimensions
Nominal
Body
Size
Inch
A
D
G (Maximum)
Class 900/1500
Class 2500
Standard Bonnet
Ext. Bonnet
Class
900/1500
Class 2500
RF,
Flanged,
or Weld
Ends
RTJ
Flanged
Ends
RF,
Flanged,
or Weld
Ends
RTJ
Flanged
Ends
1/2"
(12.7mm)
Stem
3/4"
(19.1mm)
Stem
1/2"
(12.7mm)
Stem
3/4"
(19.1mm)
Stem
Class
900/1500
Class 2500
Inches
1
10.00
10
12.13
12.13
8.31
9.38
15.38
16.00
1.81
2.12
2
12.13
12.25
15.38
15.50
9.75
10.50
16.81
17.44
2.75
3.25
mm
1
254
254
308
308
211
238
391
406
46
54
2
308
311
391
394
248
267
427
443
70
83
CVS Series DBQ Dimensions
CVS Series DBQ – Plain Bonnet
CVS Series DBQ – Extension Bonnet
