CVS Controls DBQ Series - Page 11

PARTS LISTING – 2“ CVS SERIES DBAQ – Table 5
Item
Description
Part Number
Quantity
1
Body, CVS Series DBAQ, 2”, LCC, 900/1500# RF
CVS 2U967522012
1
2
Bonnet, LCC, 3-9/16 Yoke Boss, 2” CVS DBAQ
CVS 2N1363X0022
1
3
Bonnet Flange, LCC, 2” CVS DBAQ
CVS 1N339222012
1
4*
Pin*, Valve Stem/Plug Assembly, (3/4” Stem)
See Table 6
1
5
Bonnet Gasket, 2” CVS DBAQ, HT
CVS 1L120899442
1
6
Seat Ring Gasket, 2” CVS DBAQ, HT
CVS 1N297899442
1
7*
Stem*, 3/4", 316 SST, Valve Stem/Plug Assembly
See Table 6
1
8
Hex Nut, 9/16”, ASME SA-194-2H
CVS 1C330624072
12
9
Stud Bolt, 9/16”x3.78, ASME SA-193-B7
CVS 1R387331012
12
10
Cage, Equal Percent, 17-4/HT1150
CVS 1P892339022
1
11
Seat Ring
CVS 1U274346052
1
12*
Plug*, Valve Stem/Plug Assembly, Alloy 6
See Table 6
1
13**
Packing Set**, Upper Packing, PTFE
See Table 7
1
14**
Packing Set**, Center Packing, PTFE
See Table 7
3
15**
Packing Set**, Lower Packing, PTFE
See Table 7
1
16
Packing Flange, 3/4", Steel
CVS 1E9448
1
17
Packing Flange Stud, Steel
CVS 1E9449
2
18
Packing Flange Nut, Steel
CVS 1E9446
2
19
Packing Box Ring, 316 SST
CVS 1J8733
1
20
Upper Wiper, Felt, 3/4”
CVS 1J8728
1
21
Packing Follower, 316 SST, 3/4”
CVS 1E9447
1
22
Packing Spring
CVS 1F1256
1
23
Special Washer, 3/4” SST
CVS 1F1250
1
24
Lower Wiper, TFE, 3/4"
CVS 1J8723
1
*Valve Stem, Valve Plug and Pin Sold as Assembly – See Table 6
** Items 12, 13 and 14 - Part of a complete Packing Set – See Table 7
Table 6:
Item
Description
Part Number
Quantity
4, 7, 12
Valve Stem and Plug Assembly, Alloy 6, 3/4"
CVS 2U5986X0012
1
Table 7:
Item
Description
Part Number
Quantity
13, 14, 15
PTFE Packing Set, 3/4”
CVS 1R2904
1
