CVW TX:7103 - Firmware and Specifications; Firmware Upgrade; Product Specification

Firmware upgrade Product specification
1. The operation of the wireless software upgrade of the transmitter and receiver is
the same.。
2. Download the firmware to be upgraded to a storage device such as a
USB flash drive, and connect the USB flash drive to the USB interface
of the product. After the product is powered on, the product will
automatically upgrade after reading the firmware upgrade, and the upgrade
will be completed after the product is restarted. At this time, you can
unplug the U disk (from Xie Zongna learned that you do not need to use
U disk to connect to product upgrades in the future, only need APP to do
software upgrade, one-click download and upgrade; if U disk upgrade is
required, please describe in detail, For example, what is the status of
the lights before and after the upgrade?)
project TX:
710
3
RX: 3103
Operating frequency
range
5.10~5.90 (GHz)
Video format
1080p60/59.94 、1080p50、1080p30/29.97、1080p25、1080p24/23.98、
1080psf24/23.98（SDI）
1080i60/59.94、1080i50 、
720p60/59.94 、720p50（SDI-3GA&3GB）
audio format
PCM
HDMI protocol
HDMI 1.3
；
HDMI 1.4
SDI specification
3G-SDI
、
HD-SDI
、
SD-SDI
Transmission delay
70ms
Video compression
format
H.264
Transmission distance
250m (2dbi Antenna, straight line without obstruction)
Antenna method
2T2R External
interface
DC-IN、SDI-IN、SDI-LOOP OUT、
HDMI-IN、Type-C USB、
NP-F970、
SMA *2
DC-IN、SDI-OUT*2、HDMI-OUT、
Type-C USB、NP-F970、SMA *2
button
1.POWER
；
2.CH
；
3. MODE
Working power
1.DC（7V~36V）
2. Lithium battery (SONY NP-F970 or compatible series)
Product Size
110*70*21 (Unit: mm, without battery buckle plate)
Operating temperature -10~45°C
Storage temperature
-40
℃
- 80
℃
certified product
FCC
、
CE
Installation interface
1/4 inch nut at the bottom
09 10
