c) The antenna is in the right direction and the transmission effect is the best
d) Before powering on, please make sure that the product antenna has been
installed completely
Battery life
Take SONY NPF-970 battery as an example, SONY NPF-970 battery 58WH,
transmitter working life 5-6 hours
Note: The above values are affected by the specific use environment and products
Trouble shooting
1. The transmitter and receiver cannot establish a connection
a) If the transmitter and receiver are connected to the antenna, the distance between
the transmitter and receiver is at least 1 meter
b) The transmitting frame is set to the camera head or handle at a height of 1.5-2
meters from the ground. The cameraman's body should try not to block the
antenna's cylindrical surface. The receiving frame is set to be more than 2
meters from the ground and the antenna is positive Yes, the transmission effect
is the best
2. Mosaic and stutter appear on the screen
Please confirm that the following conditions have been fulfilled：
a) When multiple sets of products work at the same time, please ensure that the
distance between the products is at least 2 meters
b) The transmitter is mounted to the camera head or handle at a height of 1.5-2
meters from the ground. The cameraman's body should try not to block the cylinder
of the antenna. The receiving rack is set to be more than 2 meters from the ground,
and the antenna is fan-shaped
c) The frequency is set between CH5-CH9
d) If multiple sets of products are used at the same time, please separate the multiple
sets of products by more than 2 meters
e) If there is a wireless guided call system on site, please separate the
guided call host and the image transmission receiver by more than 2
meters
3. The output shows a black screen
