CVW TX:7103 - Receiver Connected Without Image Output; Green Splash Screen in Output

To Next Page

To Previous Page

Please confirm whether there is OSD "connecting to transmitter" or "link

connected to transmitter, please check video source" on the black screen. If the

OSD displays "connecting to transmitter", please check according to the

transmitter and receiver cannot establish a connection "; if the OSD displays"

link connected to transmitter, please check video source ", please check the

video source or connection of the transmitter Is there a problem with the SDI /

HDMI cable

If the receiver output black screen after switching the video source resolution,

there is no video source output, please unplug the HDMI / SDI cable of the

transmitter or receiver. If the HDMI / SDI cable cannot be recovered by

plugging and unplugging, please power off and restart the transmitter and

receiver

4. The receiver is connected to the guide station or monitor

without image output

Please confirm whether the signal strength grid and VIDEO characters

are displayed on the OLED screens of the transmitter and receiver. If

there is no signal strength grid, it means that the network is not

connected. Please check according to "The transmitter and receiver

cannot be connected"; , If there is no VIDEO character, please check

the video source and the connected SDI / HDMI cable; if the

transmitter and receiver have both signal strength grid and VIDEO

characters, the monitor is blank or not displayed, please check the

receiver and monitor dock SDI / HDMI cable, change the resolution of

the camera to 1080i 50 or 720P 50 for verification; at the same time,

you can also connect the SDI / HDMI cable of the receiver to other

monitors

verification

5. A green splash screen appears in the output image

The transmitter or receiver HDMI interface is not plugged in firmly, or the camera HDMI

interface is not plugged in firmly, pluggable HDMI / SDI cable or replace HDMI / SDI cable.
