Product installation
instructions
Transmitter installation instructions
1. Please install the antenna to the antenna
interface of the transmitter as shown in the figure.
To obtain the best wireless transmission distance,
the antenna
The following picture is placed (90 ° angle between
2 antennas)
(as the picture shows)
3. Fix the transmitter to the camera head or handle through the nut hole on the
bottom of the fuselage (as shown in the figure) Warning: When the device is not
in use, the battery needs to be removed.
Receiver installation instructions
1,Please install the antenna to the antenna interface of the receiver
according to the figure.
1. Install the transmitter battery (as shown)
SWIFT 800 PRO
SWIFT 800 PRO
07
08
