Getting Connected

Last updated: 7月 12, 2022 01:16. Revision #5137

Basic Analogue Connections

Important Note: Switch the power off before making any connections.

There are two analogue connection options for the CXN (V2).

1. Line Output Connection (RCA)

2. Balanced Audio Connection (XLR)

Basic Digital Connections

There are two digital connection options for the CXN (V2).
