TECHNICAL SPECIFICATIONS
MODELS OL5KSTF
CONFIGURATION
Maximum Output Power (VA)* 5,000 VA/60HZ 4,800 VA/50HZ
Maximum Output Power (W)* 5,000 W/60HZ 4,800 W/50HZ
Form Factor Rackmount
INPUT
Nominal Input Voltage 208 Vac
Input connection type Power cord L6-30P Terminal
Input Frequency 50/60 Hz
Input Current Rating Power Cord
：
24A
/
Terminal
：
27A
OUTPUT
Nominal Output Voltage 120 Vac
UPS Outlets (12) NEMA 5-20R
PHYSICAL
Dimensions L x W x H = 23.6 x 17 x 3.4 in. (600 x 433 x 86.5mm)
Net Weight 38 kg / 83.8 lbs
ENVIRONMENTAL
Operating Temperature 32°F to 104°F (0°C to 40°C)
Operating Relative Humidity 0 to 90% Non-condensing
SAFETY
Conformance Approvals UL
* When connected with NEMA L6-30P input power cord, the output power will be derated to 4500VA/4500W
.
