Cybex Arc Trainer 610A Owner’s Manual
Main Assembly
A1 2 11090-404 Cybex Decal
A2 2 11090-405 Foot Pad
A3 1 600A-301 Arc Warranty Sheet (not shown)
A4 8 600A-311 Flange Spacer
A5 1 610A-200 Main Frame
A6 1 610A-201 Foot Plate Arm Left Rear
A7 1 610A-202 Foot Plate Arm Right Rear
A8 1 610A-203 Foot Plate Arm Left Front
A9 1 610A-204 Foot Plate Arm Right Front
A10 1 610A-205 Handle Link
A11 1 610A-208 Arm Right Hand
A12 1 610A-209 Arm Left Hand
A13 1 610A-303 Pivot Cover Right Hand
A14 1 610A-304 Pivot Cover Left Hand
A15 8 610A-311 Pivot Shaft Retainer
A16 4 610A-342 Pivot Pin
A17 2 610A-350 End Cap
A18 2 610A-351 Pivot Pin
A19 1 610A-352 Installation Poster (not shown)
A20 2 610A-356 Spacer Tube
A21 4 610A-357 Spacer Tube
A22 2 610A-358 Insert, Plastic 1.88 OD X .281 ID
A23 1 600A-200 Linkage Rod Right
A24 2 AF-16694 Pillow Block Bearing 1 Inch
A25 1 600A-201 Linkage Rod Left
A26 1 AW-18285 Harness, 610A, Frame
A27 2 AW-18286 Cable, 610A CHR Grip
A28 1 600A-101 Drive Frame Assembly
A29 4 BR030225 Retaining Ring 1.438 Internal
A30 1 CM000240 Warning Decal
A31 2 CW-17231 Wheel, Tensioner
A32 1 DE-17317 Arc Trainer Logo Decal
A33 2 DE-17339 Cybex Vortex Decal
A34 1 EW600006 Daisy Chain Jumper Cord (not shown)
A35 4 FB030232 Bearing, Radial 17MM Extended Race
A36 4 FB030244 Bearing, Radial Ball .50 ID X 1.688 OD
A37 8 FB030247 Bearing, Radial 25MM Extended Race
A38 4 FB030248 Bearing, Spherical 15MM
A39 4 FC030004 Tolerance Ring 42 (1.653) ID
A40 4 FC030005 Tolerance Ring 1.378 ID
A41 4 FC030006 Tolerance Ring 1.575 ID
A42 8 FC030007 Tolerence Ring 2.047 ID
A43 Removed 5-07
A44 1 FT-17242 Sleeve, Elevation Mounting, Top
A45 1 FT-17243 Sleeve, Elevation Mounting, Bottom
A46 8 HB-17036 Bearing, Ball .750 Diameter
A47 3 HC701226 Bolt, HHCS .375-16 X 2.0
A48 1 HC701230 Screw, HHCS .375-16 X 2.50
A49 4 HC701234 Screw, HHCS .375-16 X 3.00
A50 2 HF449064 Insert, 1.12 X 2.50-20 UNC
A51 2 HG700022 Leveling Glide, .375-16
A52 8 HM582514 Screw, Pan Head Phillips 10-32X .62
A53 2 HN704902 Locknut, .375-16 Nylon
A54 2 HN624901 Locknut, .250-20 Nylon BLK ZN
A55 2 HN704000 Hex Nut .375-16
A56 4 HN704901 Locknut, .375-16 Nylon
A57 6 HS100000 Nylon Finishing Washer No.10
A58 4 HS307602 Washer, Flat .281ID X 1.000OD X.063
A59 2 HS328300 Lockwasher Split .312
A60 4 HS347600 Washer, SAE .375
A61 10 HS347700 Washer, USS .375
A62 2 HT552516 PN Head Phil SC # 8 X .875 BLK
ITEM QTY PART NO. DESCRIPTION
A63 8 HT552512 Pan HD Phil HD Self Tapping Screw
A64 16 HT552515 Pan HD Phil HD Self Tapping Screw
A65 8 HT572512 Pan HD Phil HD Self Tapping Screw
A66 26 HT591122 Pan HD Phil HD Self Tapping Screw
A67 2 HX-16751 Cap, Frame Tube
A68 2 HX-17023 Spring Pin
A69 4 HX-17143 Internal Retaining Ring
A70 12 HX622815 SHCS .250-20 UNC-3A SS
A71 2 HX620420 BHSCS .250-20 X 1.250 SS
A72 12 HX700415 BHSCS .375-16 .75 SS
A73 4 JC700422 BHSCS .375-16 X 1.50
A74 2 JD623324 Shoulder Bolt
A75 4 JS347400 Lockwasher, Int Tooth .375
A76 1 MR-16518 Motor, Elevation. 115 V
A77 8 PL-16535 Cap, Linkage Rod, 2.00 OD
A78 2 600A-331 Cover, Crank
A79 1 600A-332 Cover, Elevation Motor
A80 1 600A-333 Cover, Right
A81 1 600A-334 Cover, Left
A82 1 600A-335 Cover, Front Access
A83 1 PL-17209 Water Bottle Holder
A84 4 PL-17279 Spacer, Shaft, Foot Plate
A85 1 PR400205 Grip 1.62 OD x 1.20 ID
A86 Removed 4-07
A87 1 610A-373 Instr., 610A Assembly Note
A88 8 HS307601 Washer, Flat
A89 2 610A-395 Arm Crank Assembly
A90 5 600A-336 Insert
A91 4 HF540200 Grommet, Nylon
A92 2 HT512517 Pan HD Phil HD Self Tapping Screw
A93 1 EW600000 Power Cord (Not Shown)
A94 1 5610A-4 Owner’s Manual (Not Shown)
A95 1 610-349-4 Warning Decal
A96 1 DE-17218-4 Heart Rate Zone Decal
A97 2 DE-17219-4 Caution Decal
A98 1 DE-17315 ETL Label
A99 1 DE-17322 Service Schedule and Error Decal
A100 1 CM000241 UL Decal
A101 1 DE-17266 UL Domestic Decal
A102 1 EW600005 Power Cord (220V Option Only)
A103 1 CM000242 CE Decal (220V Option Only)
A104 1 DE-17267 International Power Rating Decal
(220V Option Only)
A105 1 610A-300 Right Foot Plate (Black)
A105 1 610A-390 Right Foot Plate (Yellow)
A106 1 610A-301 Left Foot Plate (Black)
A106 1 610A-391 Left Foot Plate (Yellow)
A107 2 610A-302 Toe Cap (Black)
A107 2 610A-392 Toe Cap (Yellow)
A108 1 610AK014 Heart Rate Grip Kit w/o Drill Bite
A108 1 610AK022 Heart Rate Grip Kit w/ 3/8” Drill Bite
A109 2 610A-397 Caution Decal (IFI Option Only)
A110 2 610A-407 Top Plastic Sensor Grip (Black)
A110 2 610A-409 Top Plastic Sensor Grip (Yellow)
A111 2 610A-408 Bottom Plastic Sensor Grip (Black)
A111 2 610A-410 Bottom Plastic Sensor Grip (Yellow)
A112 4 HT532517 Pan HD Phil HD Self Tapping Screw
A113 1 610AK023 Total Access Conversion Kit
A114 4 HS427100 Washer, Wave
A115 2 AW-18286 Heart Rate Cable
A116 1 600A-352 Biosig Patent Label
ITEM QTY PART NO. DESCRIPTION
