Page #68 background imageLoading...
Page #68 background image
Customer
Service
Page 6-10
C1 1 600A-203 Frame, Front
C2 1 600A-313 Shaft
C3 1 630A-328 Belt, Secondary Drive, 7 Rib
C4 1 600A-337 Pully, Poly-V Die Cast, 16 Grooves
C5 2 600A-340 Bearing, 1.00 Inch Pillow Block
C6 1 600A-343 Belt, Primary Drive 16 Rib
C7 1 AD-16982 PCA, Control Board, Eddy Current
C8 1 AF-17141 Bracket, Speed Sensor
C9 1 AF-17216 Plate, Switch, Power
C10 1 AW-17098 Jumper, Power Inlet, Brown
(Not Shown)
C11 1 AW-17099 Jumper, Power Inlet, Blue
(Not shown)
C12 1 AX-17208 Assembly, ECB
C13 2 BR030221 Ring Retaining, Exterior Cresent
C14 1 CM000237 Decal, Safety Ground
C15 1 DE-17019 Disc, Speed Sensor
C16 1 EC-17096 Module, Filtered IEC-320 Power in
C17 1 EC-17097 Module, IEC Auxiliary Ac Outlet
C18 2 EF000000 Fuse 6 ASKI-BLO 5 X 20 MM 250 V
(Not Shown)
C19 1 ES000000 Switch On-Off
C20 1 EW600003 Cable Opto Sensor Armored
C21 2 FB030243 Bearing, 25 MM ID X 52 MM OD 6205
C22 1 FM-16859 Shaft, Lower
C23 2 HC661240 Screw, Hex Head Cap .312-18 x 3.75
C24 4 HC661217 HX HD Cap Screw .312-18 x 1.00
C25 4 HC701254 HX HD Cap Screw .375-16 x 5.50
C26 2 HF540201 Nut, Grommet, Spacer
ITEM QTY PART NO. DESCRIPTION
C27 4 HF579000 Nut, U type 10-24 Panel
C28 6 HJ542514 Pan Head Phillips, 8-32 x .62
External Sems Screw
C29 2 HJ582510 Pan Head Phillips, 10-32 X .38
External Sems Screw
C30 1 HM522514 Pan Head Phillips Screw, 4-40
UNC x .62
C31 1 HN586300 Nut, K- Lock 10-32 Zinc plated
C32 4 HN706300 Nut, K- Lock .375-16 UNC
C33 2 HR269600 Rivet, Dome Head .125 Dia x .188/.250
Alum/Stl Mandrel
C34 4 HS-17055 HHCS .375 x .625
C35 1 HS047300 Lockwasher, External No. 10
C36 1 HS047600 Washer, Flat SAE, .112 No. 4
C37 1 HS048300 Lockwasher Split, .112 No 4
C38 2 HS327600 Washer, SAE .312
C39 2 HS328300 Lockwasher Split .312
C40 8 HS347700 Washer, USS .375
C41 4 HS760100 Spring Retaining Washer
C42 2 HX-17023 Pin, Spring .1875 x .75 LG Type 420
C43 2 HX-17050 Bushing, 1.275 ID x 1.87 OD, Nylon
C44 4 PP660010 Finned Fastener .25 DIA x .51 Long
C45 1 PW-16521 Pully, Drive
C46 1 DE-17155-4 Warning Decal
C47 1 PL-17237-4 Controller Cover
C48 1 AX-17259 Transformer 200KVA (200V option only)
C49 3 HJ582512 Tap SC No. 10-24 x .50 PN HD Phil
(220V option only)
C50 3 HN586300 Keps 10-32-stl (220V option only)
ITEM QTY PART NO. DESCRIPTION
Front End Assembly
Cybex Arc Trainer 610A Owner’s Manual
