6. Loosen the two screws in the left inner and outer collars using a Phillips screwdriver.
QtyDescription
2Screws1
1Inner collar2
1Outer collar3
1Cover4
7. Slide the inner and outer collars onto the left cover.
8. Insert the tabs of the collars into the slots of the cover.
9. Tighten the two screws using a Phillips screwdriver.
10. Repeat steps 1 through 9 for the right side.
Install foot pads
Have one person lift the unit while a second person places a foot pad under each of the two back feet.
Qty.Description
2Foot pads1
Level unit
This procedure will level the unit by evenly adjusting the weight on the rear feet. Leveling the unit will
eliminate rocking during use.
Note: References to left and right are from the users perspective during use.
1. Verify foot plates are completely stopped.
Page 22 of 83
Cybex 626A/626AT, 627A/627AT Arc Trainer Part Number 5626-4 J
