Display video onlyTV Only
LED II on
Display data onlyData Only
LED III on
Screen is blank, video and data are not
displayed
Blank
No LED’s on
iPod/iPhone Functions
Connecting an iPod/iPhone allows some control through the keypad. The iPod/iPhone will not be charged
while connected.
1. Connect iPod/iPhone (not supplied) into the 30 pin connector.
2. Place iPod/iPhone onto the accessory tray.
3. Plug headphones (not supplied) into the console headphone jack.
4.
Press volume Up or Down to adjust volume.
5.
For non-E3 View Monitor consoles, press the Up and Down keys to change tracks.
Videos will not be displayed on the E3 View Monitor.
How power input versus displayed value is calculated
Total power, as displayed in Watts on the console, is calculated from the measured speed of the Eddy
Current Brake Flywheel and the measured current powering the Eddy Current Brake.
Testing Parameters
Displayed power (Wattage) and speed (Strides Per Minute), were found to meet class A accuracy when
compared with measured power and speed, with adjustable braking positioned in its maximum position,
at the following accuracy test points:
• 25 W, 37 SPM
• 50 W, 52 SPM
• 100 W, 72 SPM
• 150 W, 86 SPM
• 175 W, 92 SPM
• 200 W, 97 SPM
Page 56 of 83
Cybex 626A/626AT, 627A/627AT Arc Trainer Part Number 5626-4 J
