5. Install the coax cable to the mounting plate on the front of the unit using a 14 mm open end wrench.
6. Plug the Ethernet or HDMI cable into the coupler on the front of the unit.
Visually inspect unit
1. Remove any packing material from unit.
2. Examine the unit to ensure that the assembly is correct and complete.
Assembly Procedure 626AT/627AT
Two people will be required for this procedure.
Read and understand all instructions thoroughly before assembling this unit. Check all items
carefully. If there is damage, see the Customer Service section of this manual for proper procedure
to return, replace, or reorder parts.
The words "left" and "right" denote the user's orientation.
Verify you have received the correct package
1. Read box label to verify the model number and voltage (optional) match what was ordered.
2. Verify paint color matches what was ordered.
Tools Required
• Phillips screwdriver
• Stubby Phillips screwdriver
• 3/16” Allen wrench (included)
• 7/32” Allen wrench (2) (included)
• 9/16” Open end wrench (2)
Verify parts list shown below
DescriptionPart NumberQuantityItem
Base with covers attachedVaries11
Console assemblyVaries12
Foot pad12090-32223
Base, Accessory tray770A-31614
Cover, Top, Accessory tray770A-31715
Cover, Bottom, Accessory tray770A-31816
Cover, Rear, Top, Right625A-31217
Cover, Rear, Outer, Right625A-31318
Cover, Rear, Inner, Right770A-32419
Cover, Rear, Top, Left625A-310110
Page 26 of 83
Cybex 626A/626AT, 627A/627AT Arc Trainer Part Number 5626-4 J
