DescriptionPart NumberQuantityItem
3/16” Allen WrenchBK030201120
7/32” Allen WrenchBK030204221
BHSCS .375-16 x 2.25”HC700428422
Grommet, NylonHF540200123
Locknut, .375-16 NylonHN704901424
Tap Sc 10-12 × 2.00 Pn Hd PhilHT592526425
Washer, Flat .281 ID × .500 OD x .062”HS307601226
Screw, Pan Head Phillips, #6 × .50”HT532512227
Screw, Pan Head Phillips, 8-16 × .50”HT5525121928
Screw, Pan Head Phillips, 10-24 × .75”HT572515829
SHCS .250-20 UNC-3A SSHX622815230
Linkage Rod Cap 2.00 OD (1 extra)PL-16535331
LoctiteYA000201132
BHSCS. .375-16 × 4.0” (Total Access Option)JC700442133
Tube, Stop (Total Access Option)750A-438134
Page 28 of 83
Cybex 626A/626AT, 627A/627AT Arc Trainer Part Number 5626-4 J
