SECURING THE BABY
NOTE! Please remove all toys and other hard objects from
the car seat.
NOTE! Leave a maximum space of one nger between the
baby and the shoulder belts.
NOTE! Make sure that the shoulder belts (3) are not
twisted.
• Open the buckle (5).
• To loosen pull up the shoulder belts (3) while pushing
the central adjuster button (8) and pulling the shoulder
belts (3) up. Please always pull the belt tongues (7) and
not the belt pads (6).
• Place your baby into the seat.
• Put the shoulder belts (3) straight over the baby’s
shoulders.
• Join the buckle tongue sections (7) together and insert
them into the buckle (5) with an audible CLICK. Pull the
central adjuster belt (9) until the shoulder belts t the
baby‘s body snugly.
• Push the red button to open the buckle (5).
