Cyrus CD 6 SE2 - Troubleshooting Guide; Specifications

Cyrus CD 6 SE
2,
CD 8 SE
2,
CD XT SE
2,
CD T TRANSPORT User Instructions
7
TROUBLESHOOTING GUIDE
If your CD 8 SE
2
is not operating properly, disconnect the power and check all
connections using the notes in this handbook. If problems persist, the
checklist below may help.
If you are in any doubt, consult your dealer.
Disc Spinning with no sound
Switch off the power to the audio system and check that connections have
been correctly made from the CD 8
SE
2
to the amplifier.
If used with another D/A converter, check the connection from the 'DIGITAL
OUT' socket of the CD 8
SE
2
to the D/A converter. Check also that power is
applied to the D/A converter and amplifier and that the input selection and
volume control of these units is correctly set.
Pause may have been set. Check for the pause symbol on the display. Press
the PLAY/PAUSE key again on the front panel or handset to cancel pause.
Skipping tracks or distorted sound
The disc may be dirty or badly scratched. Try playing another disc. If the other
disc plays ok, try cleaning the 1
st
disc.
Indication ‘Disc error’ on the display
The disc will not read. It may be dirty or defective.
No display
The display may have been switched off at the handset. Press the display key
again to restore the display and backlight.
No Remote Operation
The handset may not be set to control the CD 8 SE
2
. Press the CD button and
retry commands.
The handset batteries may need to be replaced:
Remove the battery compartment cover located underneath the unit. Remove
the batteries and replace with new ones carefully noting the orientation
marked in the bottom of the battery case.
The batteries in the unit should only be replaced with new batteries type AAA
(I.E.C. LR03).
Specifications
Power Supply
Voltage: ........................................................................... As plate on rear of unit
Power Consumption ....................... CD 8
SE
2
............................................ 11W
CD 6
SE
2
........................................... 7.5W
CD XT
SE
2
......................................... 7.5W
CD
T TRANSPORT ................................ 7.5W
EMC & Safety Compliance (230V) ................................................................ CE
Enclosure
Dimensions (WxHxD) ........................ 215 x 75 x 365mm
Weight ............................................... CD 8
SE
2
.......................................... 3.5kg
CD 6
SE
2
.......................................... 3.1kg
CD XT
SE
2
........................................ 3.5kg
CD
T TRANSPORT .............................. 3.1kg
Material ............................................. ....................................... Die cast chassis
Audio Performance (CD 8
SE
2
)
Output Level ..........................................................................................2.1V rms
Output Impedance ...................................................................................... 50
Ω
Frequency Response ....................................................... 20-20,000Hz ±0.2dB
Channel Separation ................................................................. >124dB @ 1kHz
>103dB@20kHz
SNR (using silent track) ....................................................................... >110dBA
THD @ -10dB .......................................................................................... 0.005%
Disc compatibility ..................................................................... CD Audio, CD-R
Audio Performance (CD 6 SE
2
)
Output Level ..........................................................................................2.1V rms
Output Impedance ...................................................................................... 50
Ω
Frequency Response .......................................................... 20-20,000Hz ±1dB
Channel Separation ................................................................. >112dB @ 1kHz
>87dB@20kHz
SNR (using silent track) ....................................................................... >100dBA
THD @ -10dB .......................................................................................... 0.006%
Disc compatibility ..................................................................... CD Audio, CD-R
Audio Performance (CD XT
SE
2
)
Coaxial Digital Output .................................................................... 500mV pk-pk
Output Impedance ...................................................................................... 75
Ω
Optical Output .......................................................... Toslink optical connection
Sample rate accuracy ................................................................. 44.1k ± 50ppm
Clock Jitter ............................................................................................... <80pS
Disc compatibility ..................................................................... CD Audio, CD-R
Audio Performance (CD
T TRANSPORT)
Coaxial Digital Output .................................................................... 500mV pk-pk
Output Impedance ...................................................................................... 75
Ω
Optical Output .......................................................... Toslink optical connection
Sample rate accuracy ................................................................. 44.1k ± 50ppm
Clock Jitter ............................................................................................... <90pS
Disc compatibility ..................................................................... CD Audio, CD-R
Cyrus reserves the right to change all specifications without notice. E &OE
