Connections
Internal SCI Conductor connections
RJ45 Conductor Colour Carling terminal Housing Conductor Designation
(in relation to SCI)
1 Green/White 8 Backlighting + 2V
2 NC
3 NC
4 Brown/White 3 Switch O/P Position 1
5 Green 1 Switch O/P Position 2
6 Blue 7 NEG
7 Orange Systems on + 2V
8 Brown 2 Switch I/P centre position
Internal SCI Conductor connections
SCI Cable Connections
