D.A.S. DSP-4080 - Output Channel Parameter Editing; Output Gain Control; Output Delay

Output gain
The range of the control over the output gain is -40dB to +15dB in 0.1dB steps. Pressing EDIT the
display shows:
OP1 Output 1 Gain
Output Gain = +6.0dB
OP1 Output 1 Polar
Polarity = [+]
Output polarity
The polarity (or phase) of each output may be switched individually as
below.
Using GAIN, the phase may be changed between ‘-’ (inverted phase) or ‘+’
(non inverted phase).
Output delay
The maximum available delay between any input and output is 650mS. For
example, if the input delay on channel A is set to 500mS, the maximum
available output delay for any output fed from input A will be 150mS. The
readout units can be changed between time in milliseconds, distance in feet or
distance in metres.
OP1 Output 1 Delay
Delay = 0.0000mS
Note: The delay steps are 1mS (343mm) through FREQ, 10uS (4mm)
through Q, or 0.3uS (0.1mm) through GAIN encoder.
