D-Box 4400i User Manual

5 of 18
The D-BOX 4250i/4400i, 3 axis motion system consists of:
Description Quantity
ACM unit (Actuator Control Module) 2
Actuator (max. capacity 250 lbs each 4250i and 400 lbs each 4400i) 4
Power Cable, 6 feet (000-090-0010-Z00) 2
Single Cup, Aluminum (810-0002) 4
Screw, Bolt, Hex, Cap, 1/4-20 X 3/4, Black (100-0551)) 16
Washer, Lock, 1/4, Black (102-0051) 16
CAT5 cable, 50 feet (092-0014) 1
Included with the L bracket option – 4 actuators (#801-0006)
Washer, Lock, tooth, 1/4, Zn (102-0053) 16
Screw, Bolt, Hex, Cap, 1/4-20 X 1, Black (000-100-0555-Z00) 16
Tiewrap, 7 3/8" (190-0014) 8
L bracket 8
Clamp, Cable, 3/8” (094-0007) 2
Clamp, Cable, ½” black (094-0012) 8
Plate, Plastic, Adhesive, Tiewrap (Tiewrap) (190-0007) 2
ACM bracket 2
Required Tools
 3/8 inch drive ratchet
 3/8 inch drive 7/16 inch socket
 Phillips screwdriver / electric screwdriver
 Wire cutters
