7D-Link DIR-885L User Manual
Section 1 - Product Overview
Hardware Overview
LEDs
1 Power LED
A solid white light indicates a proper connection to the power supply. The light will be a solid orange
during boot up.
2 Internet LED
A solid light indicates connection on the Internet port. If the LED is orange, the connection is good but
the router cannot connect to the Internet.
3 Wireless (2.4 GHz) LED A solid white light indicates that the 2.4 GHz wireless band is enabled.
4 Wireless (5 GHz) LED A solid white light indicates that the 5 GHz wireless band is enabled.
5 USB 3.0 LED A solid white light indicates that a USB device detected in the USB 3.0 port.
1 2
4 5
3
