D-Link DAP-1665 Quick Installation Guide

DAP-1665
4
ENGLISH
TrOuBlESHOOTING
setuP AnD ConFiGurAtion ProBleMs
1. WHY CAN'T I ACCESS THE WEB-BASED CONFIGurATION uTIlITY?
- Check the physical connection between your computer and the access point. The LAN LED
on the access point should be illuminated, indicating that a connection is present. You should
also ensure that your computer's Ethernet port is enabled and functioning correctly.
- If you are using Wi-Fi to connect to the access point, ensure that you are connected to the
correct wireless network, and that there are no connectivity problems. If you are still unable to
access the conguration utility, try connecting to the access point using the included Ethernet
cable.
2. HOW DO I rESET MY DAP-1665 AP TO FACTOrY DEFAulT SETTINGS?
- Ensure the access point is powered on.
- Press and hold the reset button on the rear of the device for 10 seconds.
Note: Resetting the AP to the factory default will erase the current conguration settings. You
should repeat the setup process described in the installation guide above to recongure your
access point.
3. HOW DO I ADD A NEW WIrElESS ClIENT Or PC IF I HAVE FOrGOTTEN MY
WIrElESS NETWOrK NAME (SSID) Or WIrElESS ENCrYPTION KEY?
- If you have not changed your Wi-Fi settings from the factory defaults, you can use the
information listed on the provided Wi-Fi Conguration Card to connect to the access point.
- If you have changed your Wi-Fi settings, you should access the web-based conguration utility
as described on the previous page, and complete the setup wizard again to renew your wireless
settings.
- Make sure you write down these settings so that you can enter them into each wirelessly
connected device.
teCHniCAl suPPort
United Kingdom (Mon-Fri) , Website: http://www.dlink.com
Home Wireless/Broadband 0871 873 3000 (9.00am–06.00pm, Sat 10.00am-02.00pm)
Managed, Smart, & Wireless Switches, or Firewalls 0871 873 0909 (09.00am- 05.30pm)
(BT 10ppm, other carriers may vary.)
Ireland (Mon-Fri), Website: http://www.dlink.com
All Products 1890 886 899 (09.00am-06.00pm, Sat 10.00am-02.00pm)
Phone rates: €0.05ppm peak, €0.045ppm off peak times

D-Link DAP-1665 Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.4835, 5.15 - 5.35, 5.47 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1200 Mbit/s
Internal	No
Certification	CE\\r FCC\\r TELEC\\r IC\\r Wi-Fi Certified\\r VCCI
Cable lock slot type	Kensington
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK, WPS
Antenna type	External
Antenna features	Detachable antenna
Antennas quantity	2
Antenna gain level (max)	2 dBi
Input current	1 A
AC input voltage	12 V
Power consumption (typical)	5.18 W
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Package depth	274 mm
Package width	208 mm
Package height	68 mm
Package weight	669.4 g
Pallet width	1100 mm
Pallet length	1200 mm
Pallet height (air)	1989 mm
Pallet gross weight (air)	333920 g
Quantity per pallet (air)	420 pc(s)
Shipping (inner) case width	360 mm
Shipping (inner) case height	309 mm
Shipping (inner) case length	441 mm
Shipping (inner) case weight	7510 g
Shipping (inner) case net weight	3480 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	10 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	108 mm
Width	147 mm
Height	27.8 mm
Weight	222 g
