DAP-2590 Install Guide 3
Step 1: Insert provided wall anchors in the wall
where the mounting plate will be attached.
Mounting Plate Assembly
Step 2: Use the provided screws to secure the
mounting plate on the wall.
Step 3: Attach the remaining screws securely to
the back of the DAP-2590.
Step 4: Attach the DAP-2590 to the mounting
plate.
Step 5: Slide the DAP-2590 down into the grooves
on the mounting plate to secure it to the plate.
