6D-Link DCM-301 User Manual
Section 1 - Product Overview
Back Panel Connectors
7 Ethernet Port
Connect to the WAN (Internet) port on your router or to an Ethernet port on your computer using
an Ethernet cable.
8 Reset Button
Press and hold the reset button with a paper clip for 10 seconds to reset the router to the factory
default settings.
9 Coaxial Connector
Connect the cable coaxial cable to this connector. If you are sharing this connection with a TV, you
must use a coaxial splitter (not included).
10 Power Port Connect the supplied power adapter.
11 Power Button Press to turn the modem on or o.
7 8
9
10
11
