D-Link DCS-7010L Install Guide

Do not mount or connect your camera yet!
 Remove the installation CD from your package.
 Put the CD into your PC’s CD-ROM drive, and make sure your
computer has an Internet connection. The Installation Wizard will start
automatically.
If the Installation Wizard does not start, open the CD from My
Computer, and double-click the autorun.exe file.
Vista
®
Users: You need to be logged in to an account with administrative
access to use the D-Link Installation Wizard.
If you see the following screen appear, select a user account with
administrative access, enter the password if needed, then click .

If you see this screen appear, click  to continue.
3
ENGLISH
DCS-7010L_A1_QIG_v1.00(DI).indd 3 2012/5/30 上午 08:03:31

D-Link DCS-7010L Specifications

General

Maximum resolution	1280 x 720 pixels
Supported video modes	-
Video formats supported	H.264, M-JPEG, MPEG4
Supported graphics resolutions	1280 x 720 (HD 720), 1280 x 800 (WXGA)
Minimum illumination	- lx
Sensor type	CMOS
Optical sensor size	1/4 \
Optical zoom	- x
Fixed focal length	4.3 mm
Security algorithms	HTTPS
IP address filtering	Yes
Compatible memory cards	SD, SDHC
LED type	IR
Night vision distance	10 m
Type	IP security camera
Certification	CE, CE LVD
Placement supported	Outdoor
Connectivity technology	Wired
Form factor	Bullet
Mounting type	Wall
Product color	White
International Protection (IP) code	IP66
Audio system	2-way
Ethernet LAN	No
Cabling technology	10/100Base-T(X)
AC input voltage	100-240 V
DC output current	1.2 A
DC output voltage	+5V
Power source type	PoE
AC input frequency	50 - 60 Hz
Power consumption (typical)	5.4 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-25 - 50 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Compatible operating systems	Microsoft Windows 7/Vista/XP
F-number (relative aperture)	2

Weight and Dimensions

Depth	176.5 mm
Width	65 mm
Height	80.5 mm
Weight	510 g
Diameter	44 mm
