D-Link DCS-820L Quick Installation Guide

DCS-820L
32
中
文
MAC ID:XXXXXXXXXXXX
llllllllllllllllllllllllllllllllllllllllll
Wi-Fi network name:
myBabyCam-XXXX
Wi-Fi password:XXXXXXXX
安裝及設定
預設無線密碼標示位置
預設無線網路名稱為myBabyCam-XXXX
(XXXX代表攝影機MAC位址的末四碼)
1
2
請將包裝內附電源供應器(可用支援5V/2A電力的USB行動電源代替)的一端
插入攝影機背面的micro-USB電源孔，另一端插入電源插座，約30秒後將攝
影機拿起確認底部的電源指示燈已亮綠色。
請先確認您的行動裝置已可連通網路，再依行動裝置的作業系統，至
App Store或Google Play內搜尋mydlink Baby Camera Monitor並安裝。
請開啟行動裝置的Wi-Fi無線功能，搜尋攝影機的無線網路名稱並輸入
密碼連線。攝影機預設的無線資料請查看底部標籤或手冊的封底。
請開啟mydlink Baby Camera Monitor app並依精靈的指示來操作。設定
完成後您可透過app或mydlink網站(http://tw.mydlink.com)來觀看影像。
3
4

D-Link DCS-820L Specifications

General

Certification	CE, CE LVD, FCC, C-Tick
Maximum range	5 m
Motion sensor	Yes
Smartphone support	-
Compatible products	iPhone, iPad
Number of lullabies	5
Video compression formats	H.264
Mobile operating systems supported	Android 4.1, Android 4.2, Android 4.3, Android 4.4, iOS 6.0
Product color	White
Compatible memory cards	MicroSD (TransFlash)
Sensor type	CMOS
Fixed aperture	2 mm
Video resolutions	320 x 240, 640 x 480 pixels
Fixed focal length	2.5 mm
Optical sensor size	1/5 \
Minimum illumination	0 lx
Interface	Wi-Fi
Wi-Fi standards	Wi-Fi 4 (802.11n)
Depth	86 mm
Width	92 mm
Height	120 mm
Power supply	5.1 W
Dimensions (WxDxH)	92 x 86 x 120 mm
Maximum number of cameras supported	1
AC input voltage	5 V
Power source type	DC, USB
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
