D-Link DCS-820L Manual

DCS-820L Wi-Fi Baby Camera
Technical Specications
Camera
Hardware Profile • 1/5” VGA progressive CMOS sensor
• 16 ft IR light illumination distance
• Minimum illumination: 0 lux with IR LEDs on
• Built-in microphone and speaker
• Digital zoom
• Adjustable angle and pivot
• Focal length: 2.2 mm
• Aperture: F2.0
• Angle of view:
• (H) 66.22°
• (V) 49.08°
• (D) 77.04°
Image Features • Pinch & Zoom in image size • Time stamp overlay
Video Compression • H.264 video compression format • JPEG for still images
Video Resolution • 640 x 480 • 320 x 240
Audio Support • AAC
External Device Interface • 802.11n wireless
• microSDHC card slot
4
• Reset button
• Direct button
• Power port (Micro-USB)
Baby Monitoring Features
• Sound detection with adjustable sensitivity
• Motion detection with adjustable sensitivity
• Records snapshots and videos to microSD when
triggered by motion or sound
• Sends notifications when sound or motion is detected
• 2-way audio lets you listen and respond to your child
Mobile App
• Free mydlink Baby Camera Monitor app available
on the App Store® and Google Play™
• Compatible with iPhone and iPad using iOS 5.1.1 or
higher
• Compatible with Android smartphones and tablets
using Android 4.01 or higher
Network
Network Protocols • IPv4
• ARP
• TCP/IP
• UDP
• ICMP
• DHCP client
• HTTP
• HTTPS (for configuration)
• UPnP port forwarding
• RTP/RTSP/RTCP
Security • Administrator protection
• Password authentication
• HTTP and RTSP authentication
Minimum Requirements
• iPhone / iPad with iOS 5.1.1 or higher ot Android
device 4.01 or higher
• 802.11g/n Wi-Fi network (Wireless N network
recommended for optimal performance)
)
• Internet access required for remote viewing
Physical
Dimensions (L x W x H)
3.4 x 3.6 x 4.7 inches
Weight
6.2 oz
Temperature • Operating: 32 to 104 °F (0 to 40 °C) • Storage: -4 to 158 °F (-20 to 70 °C)
Humidity • Operating: 20% to 80% non-condensing • Storage: 5% to 95% non-condensing
Certifications • CE
• CE LVD
• FCC
• C-Tick
Power
•
micro USB-to-AC power adapter (included): • Can be powered by an external USB battery with at least 2 A
Input = 100-240 VAC, 50/60 Hz output (not included)
Output = 5V DC, 2A

D-Link DCS-820L Specifications

General

Certification	CE, CE LVD, FCC, C-Tick
Maximum range	5 m
Motion sensor	Yes
Smartphone support	-
Compatible products	iPhone, iPad
Number of lullabies	5
Video compression formats	H.264
Mobile operating systems supported	Android 4.1, Android 4.2, Android 4.3, Android 4.4, iOS 6.0
Product color	White
Compatible memory cards	MicroSD (TransFlash)
Sensor type	CMOS
Fixed aperture	2 mm
Video resolutions	320 x 240, 640 x 480 pixels
Fixed focal length	2.5 mm
Optical sensor size	1/5 \
Minimum illumination	0 lx
Interface	Wi-Fi
Wi-Fi standards	Wi-Fi 4 (802.11n)
Depth	86 mm
Width	92 mm
Height	120 mm
Power supply	5.1 W
Dimensions (WxDxH)	92 x 86 x 120 mm
Maximum number of cameras supported	1
AC input voltage	5 V
Power source type	DC, USB
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
