12
TECHNICAL SPECIFICATIONS
General
Standards IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
Protocol CSMA/CD
Data Transfer Rate Ethernet: 10Mbps (half duplex)
20Mbps
(full-duplex)
Fast Ethernet: 100Mbps
(half duplex)
200Mbps
(full- duplex)
Topology Star
Network Cables 10BASET: 2-pair UTP Cat. 3,4,5 (100 m), EIA/TIA- 568
100-ohm STP (100 m)
100BASE-TX: 2-pair UTP Cat. 5 (100 m), EIA/TIA-568
100-ohm STP (100 m)
Number of Ports
5 x 10/100Mbps auto-negotiation, auto MDI-X ports
Physical and Environmental
DC inputs DC 7.5V / 1A
DC 5V/1.2A
AC 9V /1A
[Different power lists would be packed for different
shipping regions ]
Power Consumption
3.5Wwatts (Max)
Temperature
Operating: 0° ~ 50° C (32º to 122º F)
Storage: -10° ~ 70° C (14ºto 158º F)
Humidity Operating: 10% ~ 90% RH, Non-condensing
Storage: 5% ~ 90% RH, Non-condensing
Dimensions (W x H x D) (approx.) 5.6 x 4.5 x 1.2 inches (142 x 115 x 31 mm)
