D-Link DES-1024D Quick Installation Guide

3
ENGLISH
To prevent accidental removal of the AC power cord, it is recommended to install the
power cord clip together with the power cord.
A. With the rough side facing down, insert the
Tie Wrap into the hole below the power
socket.
Insert Tie Wrap to the Switch
B. Plug the AC power cord into the power
socket of the Switch.
Connect the power cord to the Switch
C. Slide the Retainer through the Tie Wrap until
the end of the cord.
Slide the Retainer through the Tie Wrap
D. Circle the tie of the Retainer around the
power cord and into the locker of the
Retainer.
Circle around the power cord
E. Fasten the tie of the Retainer until the
power cord is secured.
Secure the power cord
Installing Power Cord Clip

D-Link DES-1024D Specifications

General

MAC address table	8000 entries
Store-and-forward	Yes
Maximum data transfer rate	0.1 Gbit/s
Supported data transfer rates	10/100 Mbps
10G support	No
Networking standards	IEEE 802.1Q, IEEE 802.3, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u
Switch type	Unmanaged
Switch layer	L2
Power connector	DC-in jack
Basic switching RJ-45 Ethernet ports quantity	24
Safety	UL
Product color	Black
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 90 %
Dimensions (WxDxH)	280 x 44 x 180 mm
Networking features	Fast Ethernet
Connectivity technology	Wired
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Weight	1900 g
