D-Link DFM-560EL

D-Link DFM-560EL External Modem User’s Guide
7
Chapter 3 Hardware Installation
1.Unplug the telephone from the wall socket, then plug the telephone into the socket on the
back of the modem marked PHONE.
2.Plug the telephone cord supplied into the socket on the back of the modem marked LINE.
3.Plug the other end of the cord into the wall socket.
Push Buttom
Switch
Power
Connect
RS-232C
Connect
Telephone Line
Socket
