4 Configuration D-Link Smart Managed Switch User Manual
2
2
7
7
The fields that can be configured for Management VLAN are described below:
Item Description
Management VLAN
Select to enable or disable the Management VLAN function.
VID
Select the VID to act as the managing VLAN.
Table 4.16
Click Apply to make the configurations take effect.
NOTE: When 802.1Q Management
enabled, the 802.1Q VLAN should be enabled
first.
L2 Features > VLAN > Asymmetric VLAN
The Asymmetric VLAN allows for a more efficient use of shared resources, such as server or gateway
devices.
Figure 4.35 – L2 Features > VLAN > Asymmetric VLAN
The fields that can be configured for Asymmetric VLAN are described below:
Item Description
Asymmetric VLAN
State
Specify to enable or disable the Asymmetric VLAN of the Switch.
The default value is disabled.
Table 4.17
Click Apply to make the configurations take effect.
L2 Features > VLAN > Surveillance VLAN
Surveillance VLAN is a feature that allows you to place the video traffic from D-Link IP cameras to an
assigned VLAN to enhance the IP surveillance service. With a higher priority and individual VLAN, the quality
and the security of surveillance traffic are guaranteed. The Surveillance VLAN function will check the
source MAC address and VLAN ID on the incoming packets. If it matches the specified MAC address /
VLAN ID, the packets will pass through with desired priority
To Next Page
