D-Link DIR-600L User Manual

41D-Link DIR-600L User Manual
Section 3 - Conguration
Schedules
Enter a name for the new schedule rule.
Choose the desired day(s), either All Week or Select
Days. If the latter is selected, please use the checkboxes
directly below to specify the individual days.
Tick this check box if the new schedule rule applies to
the full 24-hour period.
If the new schedule rule does not apply to the full 24-
hour period, untick the previous checkbox and then
enter a specic beginning and ending time.
Name:
Day(s):
All Day - 24 hrs:
Start Time/
End Time:
The Router allows the user the ability to manage schedule rules for various rewall and parental control features on this window.
Once you have nished conguring the new schedule rule, click the Save Settings button at the top of the window.
DIR-600L

D-Link DIR-600L Specifications

Power

power input voltage	5 V DC
power input current	1 A

Operating Environment

operating temperature	32 to 104 ˚F (0 to 40 ˚C)
operating humidity	0% to 90% non-condensing
wireless frequency range	2.4 GHz to 2.4835 GHz

Weight and Dimensions

dimensions	112 x 152 x 28 mm
weight	0.5 lb
