4D-Link DIR-610N User Manual
Section 1 - Product Overview
Hardware Overview
Connections
ID Component Description
1 LAN Ports Connect up to 4 wired devices for fast Ethernet connections
2 Internet Port Plug your broadband modem in to share your Internet connection
3 Reset Button Return the router’s settings to the factory defaults
4 Power Receptor Plug in the supplied power adapter
5 WPS Button Press this button to add wireless devices using WPS
1
2 3 5
4
