7D-Link DIR-657 User Manual
Section 1 - Product Overview
Hardware Overview
Front View
1
2
1 WPS Button
Press this button to add your device to an existing network or to create a new network.
Power LED will blink on and o when WPS button is pressed.
2 SD Card Port
Insert your SD Card for sharing multimedia les such as video, music, and images. Refer to
the SharePort Plus manual for more information. You may access the les on the SD card
by opening a web browser and enter \\dlinkrouter.
Power LED will be blinking blue when SD card is in use. Please do not eject the SD card
until the Power LED is solid blue. Removing SD card while Power LED is blinking will
cause adverse eect to your SD card.
