DIR-816L Quick Installation Guide
6. In the opened window, in the list of available wireless networks, wireless
network DIR-816LA1A (for operating in the 2.4GHz band) or DIR-
816LA1A-5G (for operating in the 5GHz band) and click the Connect
button.
7. In the opened window, enter the network key (see WPS PIN on the
barcode label on the bottom panel of the device) in the Security key
field and click the OK button.
8. Wait for about 20-30 seconds. After the connection is established, the
network icon will be displayed as the signal level scale.
!
If you perform initial configuration of the router via Wi-Fi connection,
note that immediately after changing the wireless default settings of the
router you will need to reconfigure the wireless connection using the
newly specified settings.
14
