D-Link DIR-816L

DIR-816L Quick Installation Guide
14. Click the Add button.
15. In the Name field, enter a name for the new group (IPTV).
16. From the Type drop-down list, select the Bridge value.
17. From the Tagged port drop-down list, select the internet value.
18. Select the port3 checkbox.
19. In the VLAN ID field, enter 10.
20. Click the Apply button.
You have created the group of ports for IPTV service.
21. Click the Add button.
22. In the Name field, enter a name for the new group (VOIP).
23. From the Type drop-down list, select the Bridge value.
24. From the Tagged port drop-down list, select the internet value.
25. Select the port4 checkbox.
26. In the VLAN ID field, enter 20.
27. Click the Apply button.
You have created the group of ports for access to IP telephony.
35
